| SWITCH SPECIFICATIONS: | |
| Tension | 24 V DC |
| Max current (at 25°C) | 250 mA |
| Electric circuit | PNP |
| Protection class | IP 67 (DIN 40050) |
| Cable (mm2) Length (mm) | 3x0.25 2500 |
| Temperature range (°C) | -20 +80 |
| Indicating | LED |
| Solar s.a.s - ISO 6020/2 catalogue - Hydraulic cylinders - Switch specifications |
|
|
||||||||||||||||||||
|
|
||||||||||||||||||||
